        Cisco switches can be used as plug-and-play devices out of the box but they also offer an enormous amount of features. Although the main purpose of the switch is to provide inter-connectivity in Layer 2 for the connected devices of the network, there are myriad features and functionalities that can be configured on Cisco Switches.

        In the following Cisco Switch Commands Cheat Sheet, I have tried to include the most important and frequently-used CLI commands that Cisco professionals encounter in real world networks. I know that the list is not exhaustive but I believe that the most useful commands are included.

Verification Commands

01. TestSwitch#show version

[Displays software and hardware information]



02. TestSwitch#show running-config

[Displays currently running configuration in DRAM]



03. TestSwitch#show start

[Displays configuration in NVRAM which will be loaded after reboot]



04. TestSwitch#show flash:

[Displays Flash memory information]



05. TestSwitch#show boot

[Displays boot path and image]



06. TestSwitch#show clock

[Displays the system clock]



07. TestSwitch#show interfaces

[Displays all interfaces configuration and status of line]



08. TestSwitch#show vlan

[Displays vlan number, name, status and ports associated with it]



09. TestSwitch#show vtp status

[Displays VTP mode, Number of existing vlans and config revision]



10. TestSwitch#show interface status

[Displays interface status, vlan, Duplex, Speed and type]



11. TestSwitch#show etherchannel

[Displays etherchannel information]



12. TestSwitch#show cdp neighbors

[Displays information of connected devices]



13. TestSwitch#show cdp neighbors detail

[Displays detailed information of connected devices]



14. TestSwitch#show mac address-table

[Displays current MAC address forwarding table and which MAC is learned on each switch port]



15. TestSwitch#show spanning-tree

[Displays spanning-tree state information, which interfaces are in active or blocking state etc]

Resetting the Switch



01. TestSwitch#delete flash:vlan.dat

[Deletes vlan database from flash memory so you can start adding new VLANs from scratch]



02. TestSwitch#erase startup-config

[Delete start-up file from NVRAM]



03. TestSwitch#reload

[Reboot the Switch]



Setting Host Names



01. TestSwitch#configure tertminal

[Entering into Global Configuration Mode]



02. TestSwitch(config)#hostname MySwitch

[Enter the hostname of the switch]

03. MySwitch(config)#



Setting login credentials



01. MySwitch(config)#username admin password csico1234

[create username and password for logging in to the switch]



02. MySwitch(config)#enable secret test1

[Sets encrypted secret password using MD5 algorithm. This is the enable password that you will be asked to enter when trying to enter into “enable” mode]



03.MySwitch(config)#service password-encryption

[Encrypt all the passwords using MD5]



Console Access



01. MySwitch(config)#line con 0

[Enter into line console mode]



02. MySwitch(config-line)#password test3

[Set password on console]



03. MySwitch(config-line)#login

[Enable password checking on console]



SSH/Telnet Access to the switch



01. MySwitch(config)#line vty 0 4

[Enters line vty mode for all five virtual ports]



02. MySwitch(config-line)#transport input ssh

[Enable SSH]



03. MySwitch(config-line)#transport input telnet

[Enable telnet]



04. MySwitch(configiline)#password test3

[Set password]

Setting IP Address

(To allow remote access to the switch)



01. MySwitch(config)#interface vlan1

[Enters vlan1, the native vlan]



02. MySwitch(config-if)#ip address 192.168.1.2 255.255.255.0

[Set IP address for management]



03. MySwitch(config-if)#exit

04. MySwitch(config)#ip default-gateway 192.168.1.1

[Exit path for the switch – gateway IP]



Interface description



01. MySwitch(config)#interface g0/1

      MySwitch(config-if)#description TO SERVER

Duplex and Speed Settings



02. MySwitch(config)#interface g0/1

      MySwitch(config-if)#speed 10

[Force 10Mbps Speed]



03. MySwitch(config-if)#speed 100

[Force 100Mbps Speed]



04. MySwitch(config-if)#speed auto

[Enable auto speed configuration]



05. MySwitch(config-if)#duplex auto

[Enable auto duplex configuration on switch port]



06. MySwitch(config-if)#duplex full

[Enable full duplex configuration on switch port]



07. MySwitch(config-if)#duplex half

[Enable half duplex configuration on switch port]



Setting Web-based interface for configuration (GUI)



01. MySwitch(config)#ip http server

[Enable HTTP server]



02. MySwitch(config)#ip http port 80

[Set port number for HTTP]



Port-Security



01. MySwitch(config)#interface g0/1

[Enter the interface to set port-security]

02. MySwitch(config-if)#switchport port-security

[Enable port security on the interface]

03. MySwitch(config-if)#switchport port-security mac-address sticky

[Interface converts all MAC addresses to sticky secure addresses]

04. MySwitch(config-if)#switchport port-security maximum 1

[Only one MAC address will be allowed for this port]

05. MySwitch(config-if)#switchport port-security violation shutdown

[Port will shut down if violation occurs]

06. MySwitch(config-if)#exit

07. MySwitch(config)#exit

08. MySwitch#show port-security

[Verifying Port security]

Save current configuration

01. MySwitch(config)# copy running-config startup-config

PortFast

        “Portfast” bypasses the Spanning Tree states and brings the port up as quickly as possible. Use it only if you connect a regular host (e.g Computer) on the port. Do not use this command when the port is trunk or if you connect other switches on the specific port.

02. MySwitch(config)# interface FastEthernet 0/1

03.MySwitch(config-if)# spanning-tree portfast

Configuring VLANs

01. MySwitch(config)#vlan 20

[Create a Layer2 VLAN with id 20]

02. MySwitch(config-vlan)# name testvlan

[Enter a name for the vlan]

03. MySwitch(config-vlan)#exit

04. MySwitch(config)#exit

05. MySwitch#show vlan brief

[Verify the vlan database]

06. Assigning access ports to a vlan

07. MySwitch(config)#interface g0/1

08. MySwitch(config-if)#switchport mode access

[Set the interface in switch access mode]

09. MySwitch(config-if)#switchport access vlan 20

[Assign the port to vlan 20]

10. MySwitch(config-if)#exit

The following commands will select a range of interfaces (from 1 to 24) and add all of them to vlan20

11. MySwitch(config)#interface range gigabitEthernet 0/1-24

12. MySwitch(config-if)#switchport mode access

13. MySwitch(config-if)#switchport access vlan 20

14. MySwitch(config-if)#exit

Configuring trunk port

01. MySwitch(config)#interface g0/2

02. MySwitch(config-if)#switchport trunk encapsulation dot1q

[Configure the port to support 802.1Q Encapsulation (default is negotiate)]

03. MySwitch(config-if)#switchport mode trunk

[Set the interface in permanent trunking mode]

04. MySwitch(config-if)#switchport trunk native vlan 20

[Specify native vlan for 802.1q trunks – OPTIONAL]

05. MySwitch(config-if)#switchport trunk allowed vlan 2-5

[vlans 2 to 5 are allowed to pass through the trunk]

06. MySwitch(config-if)#switchport trunk allowed vlan add 7

[add also vlan 7 in the allowed vlans]

07. MySwitch(config-if)#switchport trunk allowed vlan remove 3

[remove vlan 3 from the allowed vlans in the trunk]

08. MySwitch#show interface g0/2 trunk

[Verify the trunk ports and associated vlans on the specific interface]
